SIX

Connecting a SIX payment terminal allows you to offer a fluid payment flow to your customers and ease the work of your cashiers.

Warning

Although Worldline has acquired SIX Payment Services and both entities utilize Yomani payment terminals, their firmware differs. Terminals supplied by Worldline are, therefore, incompatible with this integration.

Configuration

Configure the payment method

  1. Go to the POS settings, scroll down to the Payment Terminals section, enable Six, and click Save. This installs the POS Six module.

  2. Create a payment method for the SIX terminal.

  3. Set the journal type as Bank.

  4. Fill in the Outstanding Account field.

  5. Select Terminal in the Integration field.

  6. Select SIX in the Use a Payment Terminal field.

  7. Enter the terminal’s IP address in the Six Terminal IP field.

  8. Click Save.

screenshot: pos-six-payment-method
menu
Point of Sale ‣ Configuration ‣ Payment Methods ‣ New
shows
A payment method form with "Integration" set to "Terminal", "Use a Payment Terminal" set to "SIX", and the "Six Terminal IP" field filled in with a local IP address.
highlight
The "Use a Payment Terminal" and "Six Terminal IP" fields (red frame).
data
Payment method named "SIX", bank journal "Bank", Six Terminal IP 192.168.1.42.
module
point_of_sale, pos_six
notes
English UI, light theme, 1440px width; scale down to about 45 % of the page width.

Note

Ensure the SIX terminal is switched on and connected to the same local network as the POS device.
